Natural Gas Compressor Packages (Under 400 HP)
Elec. Motor Prepped/ Ariel JGQ-2 (3 Stage)
Caterpillar G3304NA/ Ariel JGQ-2 (3 Stage)
Caterpillar G3304NA/ Ariel JGQ-2 (3 Stage)
- -Engine: Prepped for electric motor
- -HP Rating: 100- 200 HP @ 1800 RPM
- -Frame: Ariel JGQ-2
- -Stages: 3
- -Cylinder Configuration:
- 6.5” JG (635 psi), 4.375” P (1,270 psi), 2.75” P (1,500 psi)
- -Cooler: Air X-Changers 32VV
- MAWP- IC1: 645 psi
- MAWP- IC 2: 1,270 psi
- MAWP- AC: 1,440 psi
- -Current Condition:
- Engine removed in prep for elec. motor.
- Frame completely overhauled 4/7/2021.
Caterpillar G3304NA/ Ariel JGQ-2 (3 Stage)
Caterpillar G3304NA/ Ariel JGQ-2 (3 Stage)
Caterpillar G3304NA/ Ariel JGQ-2 (3 Stage)
- -Engine: Caterpillar G3304NA
- -HP Rating: 95 HP @ 1800 RPM
- -Frame: Ariel JGQ-2
- -Stages: 3
- -Cylinder Configuration:
- 5.75” M (480 psi), 4.375” P (1,270 psi), 2.5” P (1,440 psi)
- -Cooler: Air X-Changers 32VV
- MAWP- IC1: 645 psi
- MAWP- IC 2: 1,270 psi
- MAWP- AC: 1,440 psi
- -Current Condition:
- Engine in field-run (running) condition.
- Frame completely overhauled 5/6/2021.
Caterpillar G3304NA/ Ariel JGP-2 (2 Stage)
Caterpillar G3304NA/ Ariel JGQ-2 (3 Stage)
Caterpillar G3306NA/ Ariel JGP-2 (3 Stage)
- -Engine: Caterpillar G3304NA
- -HP Rating: 95 HP @ 1800 RPM
- -Frame: Ariel JGP-2
- -Stages: 2
- -Cylinder Configuration:
- 7.5” M (175 psi), 4.75” M (500 psi)
- -Cooler: Chart 48 VVI
- MAWP- IC1: 315 psi
- MAWP- AC: 645 psi
- -Current Condition:
- Engine: Overhauled.
- Frame: Overhauled.
- Cooler: Rodded out, hydro-tested.
- Electrical: All replaced during refurb.
Caterpillar G3306NA/ Ariel JGP-2 (3 Stage)
Caterpillar G3306NA/ Ariel JGP-2 (3 Stage)
Caterpillar G3306NA/ Ariel JGP-2 (3 Stage)
- -Engine: Caterpillar G3306NA
- -HP Rating: 145 HP @ 1800 RPM
- -Frame: Ariel JGP-2
- -Stages: 3
- -Cylinder Configuration:
- 8” M (175 psi), 5.75” P (575 psi), 3.25” P (1,125 psi)
- -Cooler: R&R U-I54.8L3
- MAWP- IC1: 300 psi
- MAWP- IC 2: 655 psi
- MAWP- AC: 1,315 psi
- -Current Condition:
- Field-run (running) condition. (Video evidence provided.)
Caterpillar G3306NA/ Ariel JGP-2 (2 Stage)
Caterpillar G3306NA/ Ariel JGP-2 (3 Stage)
Caterpillar G3306NA/ Ariel JGP-2 (2 Stage)
- -Engine: Caterpillar G3306NA
- -HP Rating: 145 HP @ 1800 RPM
- -Frame: Ariel JGP-2
- -Stages: 2
- -Cylinder Configuration:
- 8” M (175 psi), 5.5" M (480 psi)
- -Cooler: Chart 48VVI
- MAWP- IC1: 315 psi
- MAWP- AC: 645 psi
- -Current Condition:
- Engine: Overhauled.
- Frame: Overhauled.
- Cooler: Rodded out, hydro-tested.
- Electrical: All replaced during refurb.
Caterpillar G3306NA/ Gemini M302 (2 Stage)
Caterpillar G3306NA/ Ariel JGP-2 (3 Stage)
Caterpillar G3306NA/ Ariel JGP-2 (2 Stage)
- -Engine: Caterpillar G3306NA
- -HP Rating: 145 HP @ 1800 RPM
- -Frame: Gemini M302
- -Stages: 2
- -Cylinder Configuration:
- 5” M (1,250 psi),3.5” M (1,250 psi)
- -Cooler: Air X-Changers 36VV
- MAWP- IC1: 635 psi
- MAWP- AC: 1,250 psi
- -Current Condition:
- Field-run (running) condition.
- Unit inspected and painted 7/08/2020.
A.I.D. 200 HP Electric/ Ariel JGA-2 (3 Stage)
A.I.D. 200 HP Electric/ Ariel JGA-2 (3 Stage)
A.I.D. 200 HP Electric/ Ariel JGA-2 (3 Stage)
- -Driver: A.I.D. Electric Motor (460V, 3 Ph., C1D2, TEFC, Inverter Duty, VFD Ready)
- -HP Rating: 200 HP @ 1800 RPM
- -Frame: Ariel JGA-2
- -Stages: 3
- -Cylinder Configuration:
- 7.5” JG (330 psi), 5.125” P10-CE (1,200 psi), 3.25” P11-CE (1,800 psi)
- -Cooler: R&R UI-60-8N w/ new AXH Gas sections built 2011
- MAWP- IC1: 645 psi
- MAWP- IC 2: 1,287 psi
- MAWP- AC: 1,470 psi
- -Current Condition:
- Driver: NEW A.I.D. motor with 3 year warranty
- Compressor: Overhauled and made like new with new surplus tandem cylinders, piping on tandem side, divider blocks, lube pump, and MUCH more.
- Cooler: Overhauled and made like new with complete re-tube performed by Roughneck Radiator, all new bearings throughout, new sheet metal, added supports, new 15 HP Toshiba electric VFD motor, pedestal, guard, belts, etc.
- Unit: Made as new and ready to work while offering zero lead time and 40% savings over new cost!
Caterpillar G3306TA/ Ariel JGA-2 (3 Stage)
A.I.D. 200 HP Electric/ Ariel JGA-2 (3 Stage)
A.I.D. 200 HP Electric/ Ariel JGA-2 (3 Stage)
- -Engine: Caterpillar G3306TA (Removed for OH in pics but on site.)
- -HP Rating: 203 HP @ 1800 RPM
- -Frame: Ariel JGA-2
- -Stages: 3
- -Cylinder Configuration:
- 8.875” JG (230 psi), 6.125” JG (635 psi), 3.375” JG (1,320 psi)
- -Cooler: Air X-Changers 54EH
- MAWP- IC1: 645 psi
- MAWP- IC 2: 645 psi
- MAWP- AC: 1,250 psi
- -Current Condition:
- Engine: Currently removed for OH but on site.
- Compressor believed to be in field-run condition.
Caterpillar G3406NA/ Gemini H302 (3 Stage)
A.I.D. 200 HP Electric/ Ariel JGA-2 (3 Stage)
Caterpillar G3406NA/ Gemini H302 (3 Stage)
- -Engine: Caterpillar G3406NA
- -HP Rating: 215 HP @ 1800 RPM
- -Frame: Gemini H302
- -Stages: 3
- -Cylinder Configuration:
- 9” (300 psi), 6.5” (500 psi), 3.5” (1,250 psi)
- -Cooler: Chart 72VI
- MAWP- IC1: 655 psi
- MAWP- IC2: 1,315 psi
- MAWP- AC: 1,315 psi
- -Current Condition:
- Engine: Needs OH due to lack of use/improper preservation.
- Frame: Preserved and in clean, field-run condition.
- Unit: Inspected & painted Mesa Tan 5/12/21. Engine removed in preparation for engine OH.
Natural Gas Compressor Packages (400-800 HP)
Elec. Motor Prepped/ Gemini A354 (3 Stage)
Caterpillar G3412TA/ Ariel JGJ-4 (3 Stage)
Caterpillar G3412TA/ Ariel JGJ-4 (3 Stage)
- -Engine: Removed for electric motor preparation
- -Frame: Gemini A354
- -Frame Rating: 800 HP
- -Stages: 3
- -Cylinder Configuration:
- (2) 8.5”- 635 psi MAWP
- (1) 5.5”- 1,750 psi MAWP
- (1) 3.5”- 1,725 psi MAWP
- -Cooler: R&R UI 108 16U
- MAWP IC-1: 300 psi
- MAWP IC-2: 600 psi
- MAWP AC: 1,440 psi
- -Current Condition:
- Frame: Excellent, field-run condition.
- Package: Very nice and heavy with a wide skid and 2009 build date; sandblasted and primed to prevent rust damage.
Caterpillar G3412TA/ Ariel JGJ-4 (3 Stage)
Caterpillar G3412TA/ Ariel JGJ-4 (3 Stage)
Caterpillar G3412TA/ Ariel JGJ-4 (3 Stage)
- -Engine: Caterpillar G3412TA
- -HP Rating: 625 HP @ 1800 RPM
- -Frame: Ariel JGJ-4
- -Stages: 3
- -Cylinder Configuration:
- (2) 11” J (185 psi)
- 7.125” J (600 psi)
- 4.125” (1,270 psi)
- -Cooler: Amercool 132-VC
- MAWP IC-1: 300 psi
- MAWP IC-2: 645 psi
- MAWP AC: 1,250 psi
- -Current Condition:
- Engine: High hour runner; OH recommended.
- Frame: Good, field-run condition.
- Package: Very nice and heavy with a wide skid. Unit has been sandblasted and primed to prevent rust damage.
Caterpillar G3412TA/ Ariel JGJ-4 (3 Stage)
Caterpillar G3412TA/ Ariel JGJ-4 (3 Stage)
Caterpillar G3412TA/ Ariel JGJ-4 (3 Stage)
- -Engine: Caterpillar G3412TA
- -HP Rating: 625 HP @ 1800 RPM
- -Frame: Ariel JGJ-4
- -Stages: 3
- -Cylinder Configuration:
- (2) 11” J (185 psi)
- 7.125” J (600 psi)
- 4.125” (1,270 psi)
- -Cooler: Amercool 132-VC
- MAWP IC-1: 300 psi
- MAWP IC-2: 645 psi
- MAWP AC: 1,250 psi
- -Current Condition:
- Engine: High hour runner; OH recommended.
- Frame: Good, field-run condition.
- Package: Very nice and heavy with a wide skid. Unit has been sandblasted and primed to prevent rust damage.
Natural Gas Compressor Packages (Over 800 HP)
Caterpillar G3516 (SITA)/ Ariel JGT-4 (3 Stage)
Caterpillar G3516 (SITA)/ Ariel JGT-4 (3 Stage)
Caterpillar G3516 (SITA)/ Ariel JGT-4 (3 Stage)
- -Engine: Caterpillar G3516 (SITA)
- -HP Rating: 1,265 HP @ 1400 RPM
- -Frame: Ariel JGT-4
- -Stages: 3
- -Cylinder Configuration:
- (2) 17.875” T (500 psi)
- 13.625” T (635 psi)
- 7.875” T (1,800 psi)
- -Cooler: Air X-Changers 144EH
- MAWP- IC1: 200 psi
- MAWP- IC 2: 400 psi
- MAWP- AC: 1,100 psi
- -Current Condition:
- Engine: Only 3 months run time on top end overhaul; unsure of total engine hours.
- Compressor: Needs 1st stage cylinders reinstalled and compressor overhauled prior to being ready to work.
- Package: Well-built package; needs sandblasting and painting for cosmetic purposes.
Caterpillar G3516TA (A3)/ Ariel JGE-4 (2 Stage)
Caterpillar G3516 (SITA)/ Ariel JGT-4 (3 Stage)
Caterpillar G3516 (SITA)/ Ariel JGT-4 (3 Stage)
- -Engine: Caterpillar G3516 (ADEM 3)
- -HP Rating: 1340 HP @ 1400 RPM
- -Compressor: Ariel JGE-4
- -Stages: 2
- -Cylinder Configuration:
- (2) 11.5”ET (635 psi)
- (2) 6”ET (1,650 psi)
- -Cooler: Chart L156
- MAWP- IC1: 645 psi
- MAWP- AC: 1,650 psi
- -Current Condition:
- Engine: High hour (82k total pkg. hours); still in running condition and gets ran periodically. Top end OH performed at 32k hrs.
- Frame: Field-run condition.
- Package: Nice 2008 CSI package in great condition.
